Ceiling hoods - Nitro 360


Nitro 360


Intelligent Ceiling Hood

The Nitro 360 hood can only be installed to false ceiling, for which the ceiling must be constructed to withstand a weight of 30 or 40kg.

Dimmable lighting (demo)
Now you can change the visual aspect of the kitchen with the new adjustable lighting, which allows you to program the intensity and temperature (from 3000K to 4500K).

EASY-FIX
The Nitro 360 model has mounting clips, meaning it can be installed easily, quickly and effortlessly by one person.

360º Spiral Motor
The new Frecan 360º spiral motor drawer made with recycled materials, thanks to its new design uses less force to obtain better results, providing greater performance with less energy consumption and maintaining a very low noise level.

Flush mount
Due to its design, this ceiling-mounted hood is flush with the ceiling, eliminating unattractive shadows and improving aspiration.





Highlights

• Compatible with H-Connect hobs.• Silence R1000GP fan.• 360º spiral fan.• Remote control included.• Deferred stop (Last Time).• LED lighting adjustable (from 3000K to 4500K).• Easy fix tabs system.• Minimum height for technical ceiling 200 mm.• Custom made.

Technical information

Models

  • 1000-S/S-R1000GP Internal M.
  • 1000-WH-R1000GP Internal M.
  • 1300-S/S-R1000GP Internal M.
  • 1300-WH-R1000GP Internal M.
  • 1000-S/S-Without Fun
  • 1000-WH-Without Fun
  • 1300-S/S-Without Fun
  • 1300-WH-Without Fun

Downloads

Technical design

Range Hoods - Nitro 360 - Technical design

1000/1300 - Air Outlet 220 x 90 mm. o Ø150 mm.
Built-in dimensions: 970 x 475 mm / 1270 x 675 mm
Installation in fake ceiling.

Range Hoods - Nitro 360º - Technical design

1000/1300 - Air Outlet Ø200
Built-in dimensions: 970 x 475 mm

Optional items



Extra information

Installation Kit Included
Installation Kit Included
